Ozone Contact Tank Recirc System w/ 1 HP Pump

Ozone Contact Tank Recirc System w/ 1 HP Pump
Processing...
Code: OS002430

$6,995.00 $7,493.00 List Price


You May Also Want:
  • Description
  • Specs
  • Warranty
  • Info
  • Documents

In Stock. Please Allow 3 to 4 Weeks After Ordering Before Shipping

Ozone Contact Tank Recirc System w/ 1 HP Pump 220v 60 hz

Kit includes all the parts you need to assemble and pipe in your ozone recirc system
Ozone Contact Tank 16" x 72" 48 Gallon with internal distributor tube and1-1/2" NPT inlet-outlet
Maximum Flow Rate 30 GPM

Features:

  • Eliminates problems with a pressure drop across the Ozone Injector
  • Excellent water pressure and flow from faucet even if feed water pressure is low
  • As soon as the water is turned on, the flow switch allows the booster pump to operate and instantly the Ozone Injector creates a vacuum, causing the vacuum switch to close and an ozone generator to turn on.
  • Fail-safe performance: if there is no flow, a booster pump will not operate.
  • If there is water back-up from the injector, the Back-Flow Preventer will prevent water from reaching the ozone generator.

  • Includes:

  • Shipping by Truck is included in price, to lower 48 states.
  • Kit includes all the parts you need to assemble and pipe in your ozone recirc system
  • Ozone Contact Tank 16" x 72" 48 Gallon with internal distributor tube and1-1/2" NPT inlet-outlet
  • Stainless steel ozone-proof recirculation pump for driving venturi injector 1 HP 220v 60 hz
  • Mazzei venturi #484
  • Backflow preventer J-Break
  • Stainless steel ozone degass vent
  • Vacuum relief valve
  • Vacuum break with check valve to prevent water from backing up into ozone generator
  • Sch 80 PVC fittings
  • Sch 80 PVC pipe
  • Stainless steel fittings
  • Stainless steel flex lines for pump
  • Stainless steel 1" check valve
  • 1" PVC Flow switch
  • Relay control panel pre-wired





  • Weight: 110.00 lbs

    .
    5 year warranty on tank.  1 year warranty on pump and other components.
    Tank is certified.   Max flow rate though the system depends on the size ozone generator you are using and ozone demand of water.  Generally for flow rates from 5 to 35 GPM.

    Manufacturer: CWS

    Manufacturer #: OS02430
